| Technical Specification |
| Connectivity |
Bonjour, UpnP SSDP, UPnP AV, Windows Media Connect, Windows Media Player NSS, Samba, NFS. |
| BitTorrent P2P, Usenet downloader |
| NAS Access |
SMB, NFS, FTP |
| Software Specifications Video containers |
MPEG1/2/4 Elementary (M1V, M2V, M4V),MPEG1/2 PS (M2P, MPG, DAT, VOB),MPEG2 Transport Stream (TS, TP, TRP, M2T, M2TS, MTS),AVI, ASF, WMV, Matroska (MKV),MOV (H.264), MP4, RMP4, 3D BD ISO |
| Video Decoders |
XVID SD/HD,MPEG-1, MPEG-2 MP@HL, MPEG-4.2 ASP@L5, 720p, 1-point GMC, MPEG-4.10 (H.264):BP@L3, MP@L4.0, HP@L4.0, HP@L4.1,WMV9 :MP@HL,SMPTE 421M (VC-1):MP@HL, AP@L3 |
| Audio Containers |
AAC, M4A,MPEG audio (MP1, MP2, MP3, MPA),WAV, WMA, FLAC, OGG |
| Audio Decoders |
DTS, WMA, WMA Pro,MPEG-1 Layer 1, 2, 3, MPEG-4 AAC-LC, MPEG-4 HE-AAC, MPEG-4 BSAC ,LPCM, FLAC, Vorbis, TrueAudio, APE Audio |
| Audio Passthrough |
DTS, DTS-HD HR, DTS-HD MA |
| Other Formats |
ISO, IFO navigation, Simple BD navigation |
| Photo Formats |
JPEG, BMP, PNG, GIF |
| Subtitle Formats |
SRT, MicroDVD SUB, SSA, SUB/IDX |
| Hardware Specifications Chipset |
Sigma Designs SMP8911 Dual-Core 800Mhz with 512KB L2 Cache with VXP Video Processor |
| Memory |
1024MB DDR2, 256MB SLC NAND Flash |
| Audio/Video |
HDMI, Component, CVBS, Stereo Audio, S/PDIF, Digital Optical |
| Other Interface |
Power LED and Standby LED, 2x USB 2.0 Host, 1 x USB 3.0 Slave, 1 x eSATA, quick dock mounting for 2.5" or 3.5" SATA HDD, Infra-Red Remote Control, SD card reader, IR-Receiver Port |
| Network |
Ethernet 10/100/1000 Mbps |
| Power |
12V DC, 3.5A Max |
| Dimension |
182mm (W) x 158mm (L) x 56mm (H) (7.2" x 6.2" x 2.2") |
| Weight |
1.3kg (2.86lbs) |
