HELIX M FOUR (HA14107)
| Power RMS ≤ 1% THD+N | |
| - @ 4 Ohms | 4 x 100 Watts |
| - @ 2 Ohms | 4 x 100 Watts |
| - @ 1 Ohm | - |
| - bridged @ 4 Ohms | 2 x 200 Watts |
| - bridged @ 2 Ohms | - |
| Max. output power per channel* | Up to 135 Watts RMS @ 4 / 2 Ohms |
| Amplifier technology | Class D |
| Inputs | 6 x RCA / Cinch 6 x Highlevel speaker input 1 x Optical SPDIF (12 - 96 kHz) 1 x Remote In |
| Input sensitivity | RCA / Cinch 1 - 4 Volts Highlevel 5 - 20 Volts |
| Input impedance RCA / Cinch | 22 kOhms |
| Input impedance highlevel | 9 - 33 Ohms or 20 kOhms |
| Outputs | 4 x Speaker output 6 x RCA / Cinch 2 x Remote Out |
| Output voltage RCA / Cinch | 6 Volts RMS |
| Frequency response | 20 Hz - 22,000 Hz |
| DSP resolution | 64 Bit |
| DSP power | 295 MHz (1.2 billion MAC operations/second) |
| Sampling rate | 48 kHz |
| DSP type | Audio signal processor |
| Signal converters | A/D: AKM 32 Bit D/A: AKM 32 Bit |
| Signal-to-noise ratio digital input | 105 dB (A-weighted) |
| Signal-to-noise ration analog input | 102 dB (A-weighted) |
| Distortion (THD) | < 0.03 % |
| Damping factor | 100 |
| Operating voltage | 10.5 - 16 Volts (max. 5 sec.down to 6 Volts) |
| Idle current | 1500 mA |
| Max. remote output current | 500 mA |
| Fuse | 2 x 30 A Maxi-fuse (APX) |
| Additional features | ADEP.3 circuit, Auto Remote switch, 32 Bit CoProcessor, Control Input |
| Dimensions (H x W x D) | 50 x 230 x 154 mm / 2.00 x 9.06 x 6.06“ |
General parameters
| Manufacturer | HELIX |
|---|
Sound
| Number of channels | 4 |
|---|---|
| Signаl/Noise Ratio | 98 |
| Continuous power, W | 200 |
| Impedance, Om | 1-4 |
Size
| Dimensions, mm | 50x230x154 |
|---|
Weight
| Gross weight (kg) | 10 |
|---|
Warranty
| WarrantyFor business customers the warranty is 1 year, unless a shorter period is stated. | 2 years |
|---|
