| Processor |
Sigma Designs 8672/8673 |
| RAM |
512 MB |
| Flash memory |
256 MB |
| Connectors |
HDMI 1.4, 2x USB 2.0 (1x rear, 1x side), composite, component, analog stereo outputs, USB 3.0 slave, Ethernet 10/100/1000 Mb/s, Wi-Fi 802.11n, SD card slot (side), power input, power switch (back), LED indicator (front) |
| Internal storage |
Internal HDD rack with hot swap function for SATA HDD 2.5". USB 3.0 slave interface and provided USB 3.0 (slave-host) cable allow fastest possible way of transferring data between PC and player |
| Media sources |
external HDD (USB), external optical drive (USB), USB devices (USB flash drive, USB card reader, etc), built-in SD card reader (SD/SDHC), PC and NAS in local network (SMB, NFS, UPnP, HTTP), other Internet and local network media sources (HTTP, multicast UDP RTP) |
| Web Browser |
Opera, WebKit |
| DLNA |
DLNA (1.5 or 2.0) client support |
| Adobe Flash |
3.1 (Lite, standalone) supported |
| Streaming protocols |
MPEG-TS over multicast-UDP, MPEG-TS over multicast-RTP, MPEG-TS over HLS, MPEG-TS over RTSP, MPEG-TS over HTTP, MP4 over HTTP, raw-MP3 over HTTP, raw-AAC over HTTP |
| DRM options |
PlayReady, Verimatrix, Secure Media. Other DRM can be added by request |
| Video codecs |
MPEG2, MPEG4, XVID, WMV9, VC1, H.264; support for very high bitrate video (up to 50 MBit/s and higher) |
| Video file formats |
MKV, MPEG-TS, MPEG-PS, M2TS, VOB, AVI, MOV, MP4, QT, ASF, WMV, BDMV, DVD-ISO, VIDEO_TS |
| 3D Video Support |
MVC, Side-by-side, Top/Bottom |
| Video output modes |
wide range of supported output resolutions (up to 1080p) and framerates (including 23.976p, 24p, PAL, NTSC) |
| Video output framerate |
automatic (according to the played content) and manual |
| Audio codecs |
AC3 (Dolby Digital), DTS, MPEG, AAC, LPCM, WMA, WMAPro, FLAC, multichannel FLAC, Ogg/Vorbis; support for very high quality audio (up to 192 kHz / 24-bit) |
| Audio file formats |
MP3, MPA, M4A, WMA, FLAC, APE (Monkey’s Audio), WV Pack, Ogg/Vorbis, WAV, AC3, AAC |
| Subtitle formats |
SRT (external), SUB (MicroDVD) (external), text (MKV), SSA/ASS (MKV, external), VobSub (MP4, MKV, external SUB/IDX), PGS (Blu-ray, TS, MKV) |
| Hardware 3D Graphics Acceleration |
OpenGL support |
| Picture file formats |
JPEG, PNG, BMP, GIF |
| Playlist file formats |
M3U, PLS |
| Photo viewer functions |
slideshow, transition effects, picture rotation, zoom, browse playlist, repeat, shuffle Audio playback functions |
| Filesystems |
FAT16/FAT32 (read-write), EXT2/EXT3/EXT4 (read-write), NTFS (read-write) |
| Ethernet |
10/100/1000 Mb/s |
| Wi-Fi |
Internal Wi-Fi (b/g/n) module |
| Dune Network Playback Accelerator |
special optimizations ensuring best-in-class network playback performance for the Sigma Designs 864x-865x-867x platform and enabling smooth playback of any supported kind of media content via any network protocol (including NFS and SMB) even in 100 Mbit/s Ethernet networks. |
