Features:

This range of devices is so updated that Autel upgrades provide the latest OE-level coverage for more than 80 U.S. local, Asian and European vehicles, including even supercars.

Exclusive OE level functionality from comprehensive OBDII diagnostics and services to advanced ECU coding and programming.

Automatic system and software updates with real-time notifications over an Internet connection.

Interactive data logging sessions allow you to contact Autel directly to troubleshoot diagnostic errors and other issues for the first time.

One-stop multifunction work for ideal management of garage and autoelectric operations so that all data files, customer information and vehicle records are conveniently handled and handled.

All data about the customer’s cars is stored in the cloud, as well as vehicle records, scanner data, and technician notes.

Video library for troubleshooting and direct links to troubleshooting.

ADAS calibration software available (optional).

Technical characteristics:

Operating system; Android 7.0

Processor: Samsung Exynos 8895V eight-core processor (2.3 GHz quad-core Mongoose + 1.7 GHz quad-core A53)

Memory: 4 GB RAM and 128 GB internal memory

Display: 9.7-inch TFT-LCD with 1536 x 2048 resolution and touch screen

Communication interfaces: WiFix2 (802.11 a / b / g / n / ac 2x2 MIMO); BT v.2.1 + EDR; GPS; USB 2.0 (two Type A USB HOST, one USB mini); HDMI 2.0; SD card (supports up to 256 GB)

Rear camera: rear 16 megapixels, autofocus with flashlight

Front camera: 5.0 megapixels

Tablet sensors: gravity accelerometer, ambient light sensor (ALS)

Audio input / output: microphone, dual speakers, 3-way 3.5 mm stereo / standard headphone jack

Power and battery: 15000mAH 3.8 V lithium polymer battery, rechargeable via 12V AC / DC power supply

Input voltages: 12V / 3A adapter

Operating temperature: 0 to 50 ° C

Storage temperature: -20 to 60 ° C

Housing: rubberized outer protection and sturdy inner housing

Dimensions: 304.4 mmx 227.8 mmx 42.5 mm

Weight: 1.66 kg

Protocols: DoIP, PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 single wire can (GMLAN), ISO-11898-2, ISO-11898-3, SAE-J2819 (TP20), TP16 , ISO-9141, ISO-14230, SAE-J2610 (Chrysler SCI), UART echo byte, SAE-J2809 (Honda Diag-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD bus), Ford UBP, Nissan DDL UART with watch, BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708, SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM class 2)

Equipment:

Tablet PCs

MaxiFlash VCMI

Main OBDII cable V2.0

AC / DC adapter 12V

Car charging cable

2 pcs. fuses

4 pcs. oscilloscope test leads

2 pcs. multimeter test leads

2 pcs. secondary ignition wires

2 pcs. suppressors

4x6 pcs. probes

1x2 pcs. multimeter probes

2x2 pcs. flexible probes with connections

1x5 pcs. reverse mounting probes (red / green / blue / yellow / black)

2 pcs. screwed back probe mounts

20 pcs. flexible needles

2x2 pcs. small terminals

1x2 pcs. large terminals
